OPTALIGN Touch
OPTALIGN touch was designed by some of the world’s leading alignment experts to solve problems in the easiest way possible. Featuring the unique sensALIGN 5 laser and sensor heads, it enables powerful, fast, and efficient ways to align machine shafts.
Designed for standard machines and everyday tasks, OPTALIGN Touch combines hardware, software, and WiFi connectivity to deliver precise alignment data via the cloud. Its intuitively guided user interface can be operated by almost anyone – users just need to follow the three steps for any laser shaft alignment procedure: dimensions, measure, and result.
The OPTALIGN Touch offers all well-known PRUFTECHNIK features necessary for every day alignment jobs: SWEEP mode measurement, simultaneous Live Move, InfiniRange, flip machines functionality, soft foot detection, dynamic tolerance (TolChek), thermal growth compensation and many more.
Key benefits:
OPTALIGN® touch device
CPU:
Processor: 1.0 GHz quad core ARM® Cortex-A9
Memory: 2 GB RAM, 1 GB Internal Flash, 32 GB SD-Card Memory
Display:
Technology: Projective capacitive multi-touch screen
Type: Transmissive (sunlight-readable) backlit TFT color graphic display Optically bonded, protective industrial display, integrated light sensor for automated adjustment of the brightness to the display
Resolution: 800 x 480 Pixel
Dimensions: 178 mm (7”) diagonal
LED indicators: 3 LEDs for battery status, 1 LED for WiFi communication
Power supply
Operating time: 12 hours typical use (based upon an operating cycle of 25% measurement, 25% computation, 50% ‘sleep’ mode)
Battery: Lithium-ion rechargeable battery 3.6 V / 80 Wh
AC adapter/charger: 12 V / 36 W; standard barrel connector (5.5 x 2.1 x 11 mm)
External interface:
sensALIGN® 5 sensor
5-axis sensor: 2 planes (4 displacement axes and angle)
Measurement area: Unlimited, dynamically extendible
Resolution: 1 μm (0.04 mil) and angular 10 μRad
Accuracy (avg): > 98%
Measurement rate: approx. 20 Hz
Inclinometer error: 0.3% full scale
Inclinometer resolution: 0.1°
LED indicators:
1 LED for laser adjustment and battery status
1 LED for Bluetooth® communication
Power supply:
Battery: Lithium-Ion rechargeable battery 3.7 V / 5 Wh
Operating time: 10 hours (continuous use)
Charging time: Using charger – 2.5 h for up to 90%; 3.5 h for up to 100%; Using USB port – 3 h for up to 90%; 4 h for up to 100%
External interface: Integrated Bluetooth 4.1 Smart Ready wireless communication USB 2.0 Full Speed
sensALIGN® 5 laser
Type: Semiconductor laser diode
Beam power: < 1mW
Inclinometer error: ± 0.3% full scale
Inclinometer resolution: 0.1°
Beam divergence: 0.3 mrad
Wavelength: 630 – 680 nm (red, visible)
Laser class:
Class 2 according to IEC 60825-1:2014. The laser complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Power supply:
Batteries: 2 x 1.5 V IEC LR6 (“AA“)
Operating time: 180 hours
